222FF Series slim line relay coils with resistance, wire gauge, and turn count; shared housing 41/64" ID × 1-3/32" OD × 1-15/16" long

222FF Series Slim Line Relay Coils – Resistance & Winding Variants

SKU:
222FF1
Current Stock:
Description

222FF Series Slim Line Relay Coils – Resistance & Winding Variants

The 222FF Series includes slim line relay coils with a standard housing size: 41/64" ID × 1-3/32" OD × 1-15/16" long, unless otherwise noted. Each model varies by resistance, wire gauge, and winding turns.

View Slim Line Coil Specifications
Model Resistance (Ω) Wire Gauge Turns Dimensions
222FF1 3379 #41 10,941 41/64" × 1-3/32" × 1-15/16"
222FF5 200 #35 2,736 41/64" × 1-3/32" × 1-15/16"
222FF6 15.8 #29 860 41/64" × 1-3/32" × 1-15/16"
222FF7 3136 — — 41/64" × 1-3/32" × 1-15/16"
222FF8 796 #37 6,420 41/64" × 1-3/32" × 1-15/16"
222FF9 1849 #39 9,345 41/64" × 1-3/32" × 1-15/16"
222FF11 194 #34 3,192 41/64" × 1-3/32" × 1-15/16"
222FF12 394 #36 4,136 41/64" × 1-3/32" × 1-15/16"
222FF13 11.5 #28 780 41/64" × 1-3/32" × 1-15/16"
