ALLWEILER ALLIFT 210-43 submersible elevator screw pump with aluminum housing and steel discharge connection

ALLWEILER ALLIFT 210-43 – Submersible Elevator Screw Pump (105 GPM, 17.6 HP)

AFD
SKU:
210-43
Current Stock:
Description

ALLWEILER ALLIFT 210-43 | Submersible Elevator Screw Pump

The ALLWEILER ALLIFT 210-43 is a high-performance submersible screw pump designed specifically for hydraulic elevator systems. With a flow rate of up to 105 GPM and a power rating of 17.6 HP, this pump ensures efficient and reliable operation. Its robust construction and optimized design make it ideal for both commercial and residential elevator applications.

Key Features
  • Flow rate: Up to 105 GPM
  • Power: 17.6 HP
  • Motor speed: 3400 RPM
  • Compact and lightweight design (34 lbs)
  • Suitable for mineral oil-based hydraulic fluids
  • Optimized for low noise and vibration levels
Applications
  • Hydraulic elevator systems
  • Commercial and residential buildings
  • Modernization projects requiring efficient fluid movement
  • Systems utilizing mineral oil-based hydraulic fluids
Specifications
  • Model: ALLIFT 210-43
  • Flow Rate: 101–105 GPM
  • Power: 17.6–34.2 HP
  • Motor Speed: 3400 RPM
  • Weight: 15.5 kg (34 lbs)
  • Operating Temperature: 0°F to 180°F
  • Viscosity Range: 150 SSU
Construction & Design
  • Housing: Aluminum alloy rotor housing
  • Discharge Connection: Steel
  • Power Rotor: Steel
  • Idler Rotors: Pearlitic gray iron
  • Mounting: Flange mounted directly to most popular submersible motors
  • Inlet: Submersed in tank with stainless steel strainer
Additional Information
ItemAliasNos:
210-43
