3RT2517-1AK60 – 5.5 kW Contactor, 4-Pole

The Siemens 3RT2517-1AK60 is a 3RT2 series motor contactor. Rated for 5.5 kW at 400V and 12 A under AC-3 conditions, with a 110 V AC 50 Hz / 120 V AC 60 Hz coil and 2 NO + 2 NC auxiliary contacts. 4-pole configuration. Mounting: Screw terminal. Mechanical life: 10 million operations.

Key Specifications
ManufacturerSiemens
SeriesSIRIUS 3RT2
Catalog Number3RT2517-1AK60
SizeS00
Poles4
Rated Power (400V)5.5 kW
Rated Current (AC-3 400V)12 A
Control Voltage110 V AC 50 Hz / 120 V AC 60 Hz
Auxiliary Contacts2 NO + 2 NC
Coil TypeAC
MountingScrew terminal
Shared Specifications
  • General
    • Mounting: DIN rail or screw mounting
    • Standards: IEC 60947-4-1, UL 60947-4-1, CSA C22.2
    • Ambient Temperature: -25 °C to +60 °C
    • Degree of Protection: IP20 (terminals), IP40 (housing)
    • Auxiliary Contacts: Snap-on front or side-mounted modules
    • Coil Voltage Options: AC/DC coils, wide voltage range
    • Switching Capacity: Up to 100 kA short-circuit current with fuse protection
    • LED Indication: Optional status indication for operating state
    • Accessories: Compatible with timing relays, overload relays, suppressors
    • Enclosure: Finger-safe housing with integrated suppressor elements (optional)
    • Certification: CE, UL, CSA, CCC, EAC

Download Manual (PDF)

Additional Information
ItemAliasNos:
3RT2517-1AK60
