DPA53CM48 - Power Monitor, Carlo Gavazzi 380-480vac

DPA53CM48 - Carlo Gavazzi | Elevator 3-Phase Voltage Monitoring Relay

The DPA53CM48 3-phase monitoring relay protects elevator traction and control circuits by detecting incorrect phase sequence, phase loss, and undervoltage on 380–480 VAC (±15%) lines. A front-dial knob lets you fine-tune the undervoltage setpoint for reliable fault response even under regenerated voltage conditions.

Housed in a slim 17.5 mm DIN-rail enclosure, the DPA53CM48 is powered directly by the measured phases and features a SPDT electromechanical relay output rated 5 A @ 250 VAC. Green and yellow LEDs indicate power-on and relay status. Operating over 50–60 Hz, it’s IP20-rated and UL-recognized for North America and CE-marked for global use.

• Monitors phase sequence, phase loss, and undervoltage on 380–480 VAC three-phase lines
• Front-dial adjustable undervoltage setpoint (320–480 VAC range)
• Self-powered by measured phases; no separate supply needed
• SPDT relay output rated 5 A @ 250 VAC resistive
• Slim 17.5 mm PA66/NORYL® DIN-rail housing (DIN 43880)
• Green “Power On” and yellow “Relay On” LEDs
• IP20 protection; operating temperature –20 °C to +60 °C (50 Hz) / –20 °C to +50 °C (60 Hz)
• UL Recognized (US & Canada), CE, CSA, CCC certified

The DPA53CM48 delivers compact, code-compliant phase protection to minimize elevator downtime and equipment damage. Always verify voltage range and mounting compatibility before installation.
