WS58 Wedge Sockets – 5/8″ Rope, 12–42″ x 3/4″ Rods
WS58 Series | Elevator Rope Wedge Sockets
WS58 Series Rope Wedge Sockets are engineered for 5/8" elevator ropes and come with durable 3/4" diameter rods in lengths from 12" to 42". Built for strength and simplicity, these sockets deliver consistent, safe anchoring for hoist, car, and compensating cable applications.
Replace old babbit sockets and enjoy faster, safer installation without the risk of fire or improper pours. Wedge sockets eliminate the need for messy babbit or resin methods, saving time and labor during reroping or cable adjustments.
- Save labor costs on babbit and resin socketing
- Discard old sockets when reroping or adjusting stretch—much faster
- Easy installation and cable adjustment
- Approved in all 50 states including Los Angeles, Chicago, and New York
- Tested for high tensile strength: 31,600 lbs on 6x19 wire rope
- Suitable for heavy freight elevators, high-speed gearless systems, and compensating rope use
- Meets and exceeds ANSI A17.1 Rule 212 and Canadian B44 elevator code requirements
- Includes socket, pre-assembled rod with roll pin, two nuts, washer, cotter pin, and two wire clips
View Wedge Socket Specifications
| Model | Rope Size | Rod Dimensions | Application |
|---|---|---|---|
| WS5812 | 5/8" | 12" × 3/4" dia. rod | Car or hoist rope anchor |
| WS5818 | 5/8" | 18" × 3/4" dia. rod | Elevator governor rope |
| WS5824 | 5/8" | 24" × 3/4" dia. rod | Traction and compensating systems |
| WS5830 | 5/8" | 30" × 3/4" dia. rod | Freight elevator installs |
| WS5836 | 5/8" | 36" × 3/4" dia. rod | Deep pit elevator layouts |
| WS5842 | 5/8" | 42" × 3/4" dia. rod | Extended lift installations |
WS58 Series wedge sockets simplify heavy-duty elevator rope terminations and improve on-site install efficiency. Confirm your rope and rod specs before use.
